| Manufactured in 1 to 10 elements | |
| Nominal flow rate | 120 l/min |
| MAX working pressure | 250 bar |
| MAX return backpressure | 80 bar |
| Standard PRESSURE RELIEF valve, may be set. | da 30 a 250 bar |
| Single-acting check valve for each element Negative spool overlapping | |
| Reversing spool for right-hand or left-hand inlet Preset for CARRY-OVER | |
| Working temperature | min.-30°C ÷ max. 80°C |
| MAX spool leakage at 100 bar (Temp. 50°C Visc. 27 CST) | 21 ml/min |
| MODEL | L (MM) | F (MM) | WEIGHT (KG) |
| AMI 12C/1 (1 section) | 168 | 118 | 18,600 |
| AMI 12C/2 (2 sections) | 216 | 166 | 24,900 |
| AMI 12C/3 (3 sections) | 264 | 214 | 31,200 |
| AMI 12C/4 (4 sections) | 312 | 262 | 37,500 |
| AMI 12C/5 (5 sections) | 360 | 310 | 43,800 |
| AMI 12C/6 (6 sections) | 408 | 358 | 50,100 |
| AMI 12C/7 (7 sections) | 456 | 406 | 56,400 |
| AMI 12C/8 (8 sections) | 504 | 454 | 62,700 |
| AMI 12C/9 (9 sections) | 552 | 502 | 69,000 |
| AMI 12C/10 (10 sections) | 600 | 550 | 75,300 |
| Manufactured in 1 to 10 elements | |
| Nominal flow rate | 120 l/min |
| MAX working pressure | 250 bar |
| MAX return backpressure | 80 bar |
| Standard PRESSURE RELIEF valve, may be set. | da 30 a 250 bar |
| Single-acting check valve for each element Negative spool overlapping | |
| Reversing spool for right-hand or left-hand inlet Preset for CARRY-OVER | |
| Working temperature | min.-30°C ÷ max. 80°C |
| MAX spool leakage at 100 bar (Temp. 50°C Visc. 27 CST) | 21 ml/min |
| MODEL | L (MM) | F (MM) | WEIGHT (KG) |
| AMI 12C/1 (1 section) | 168 | 118 | 18,600 |
| AMI 12C/2 (2 sections) | 216 | 166 | 24,900 |
| AMI 12C/3 (3 sections) | 264 | 214 | 31,200 |
| AMI 12C/4 (4 sections) | 312 | 262 | 37,500 |
| AMI 12C/5 (5 sections) | 360 | 310 | 43,800 |
| AMI 12C/6 (6 sections) | 408 | 358 | 50,100 |
| AMI 12C/7 (7 sections) | 456 | 406 | 56,400 |
| AMI 12C/8 (8 sections) | 504 | 454 | 62,700 |
| AMI 12C/9 (9 sections) | 552 | 502 | 69,000 |
| AMI 12C/10 (10 sections) | 600 | 550 | 75,300 |
