MONOBLOCK DIRECTIONAL CONTROL VALVE
AmioleodinamicaAmioleodinamica
| Manufactured in 2 to 7 sections | |
| Nominal flow rate | 35 l/min |
| MAX working pressure | 300 bar |
| MAX return backpressure | 80 bar |
| Standard PRESSURE RELIEF valve, may be set (on request may be set from 10 to 250 bar) | da 60 a 300 bar |
| Reversing spool for right-hand or left-hand inlet Positive spool overlapping | |
| Working temperature | min.-30°C ÷ max. 80°C |
| MAX spool leakage at 100 bar (Temp. 50°C Visc. 27 CST) | 18 ml/min |
| MODEL | L (MM) | F (MM) | WEIGHT (KG) |
| AMI 4 (2 sections) | 134 | 110 | 4,200 |
| AMI 4 (3 sections) | 170 | 146 | 5,400 |
| AMI 4 (4 sections) | 206 | 182 | 6,600 |
| AMI 4 (5 sections) | 242 | 218 | 7,800 |
| AMI 4 (6 sections) | 278 | 254 | 9,100 |
| AMI 4 (7 sections) | 314 | 290 | 10,400 |
| Manufactured in 2 to 7 sections | |
| Nominal flow rate | 25 l/min |
| MAX working pressure | 200 bar |
| MAX return backpressure | 10 – 12 bar |
| Standard PRESSURE RELIEF valve, may be set (on request may be set from 10 to 250 bar) | da 60 a 300 bar |
| Reversing spool for right-hand or left-hand inlet Positive spool overlapping | |
| Working temperature | min.-30°C ÷ max. 80°C |
| MAX spool leakage at 100 bar (Temp. 50°C Visc. 27 CST) | 30 – 35 ml/min |
| Absorption | |
| for 12 Vdc (H70) | 36 Watt, 3 Ampere |
| for 24 Vdc (H71) | 36 Watt, 1,50 Ampere |
| MODEL | L (MM) | F (MM) | WEIGHT (KG) |
| AMI 4 (2 sections) | 134 | 110 | 4,800 |
| AMI 4 (3 sections) | 170 | 146 | 6,600 |
| AMI 4 (4 sections) | 206 | 182 | 8,500 |
| AMI 4 (5 sections) | 242 | 218 | 10,400 |
| AMI 4 (6 sections) | 278 | 254 | 12,000 |
| AMI 4 (7 sections) | 314 | 290 | 13,900 |
| Manufactured in 2 to 7 sections | |
| Nominal flow rate | 35 l/min |
| MAX working pressure | 300 bar |
| MAX return backpressure | 80 bar |
| Standard PRESSURE RELIEF valve, may be set (on request may be set from 10 to 250 bar) | da 60 a 300 bar |
| Reversing spool for right-hand or left-hand inlet Positive spool overlapping | |
| Working temperature | min.-30°C ÷ max. 80°C |
| MAX spool leakage at 100 bar (Temp. 50°C Visc. 27 CST) | 18 ml/min |
| MODEL | L (MM) | F (MM) | WEIGHT (KG) |
| AMI 4 (2 sections) | 134 | 110 | 4,200 |
| AMI 4 (3 sections) | 170 | 146 | 5,400 |
| AMI 4 (4 sections) | 206 | 182 | 6,600 |
| AMI 4 (5 sections) | 242 | 218 | 7,800 |
| AMI 4 (6 sections) | 278 | 254 | 9,100 |
| AMI 4 (7 sections) | 314 | 290 | 10,400 |
| Manufactured in 2 to 7 sections | |
| Nominal flow rate | 25 l/min |
| MAX working pressure | 200 bar |
| MAX return backpressure | 10 – 12 bar |
| Standard PRESSURE RELIEF valve, may be set (on request may be set from 10 to 250 bar) | da 60 a 300 bar |
| Reversing spool for right-hand or left-hand inlet Positive spool overlapping | |
| Working temperature | min.-30°C ÷ max. 80°C |
| MAX spool leakage at 100 bar (Temp. 50°C Visc. 27 CST) | 30 – 35 ml/min |
| Absorption | |
| for 12 Vdc (H70) | 36 Watt, 3 Ampere |
| for 24 Vdc (H71) | 36 Watt, 1,50 Ampere |
| MODEL | L (MM) | F (MM) | WEIGHT (KG) |
| AMI 4 (2 sections) | 134 | 110 | 4,800 |
| AMI 4 (3 sections) | 170 | 146 | 6,600 |
| AMI 4 (4 sections) | 206 | 182 | 8,500 |
| AMI 4 (5 sections) | 242 | 218 | 10,400 |
| AMI 4 (6 sections) | 278 | 254 | 12,000 |
| AMI 4 (7 sections) | 314 | 290 | 13,900 |
